DIY Pedal build - Rookie Style!!

Ok, with the chip removed from the socket, can we check for 9V+ at pin 8, & also for ground at pin 4?
OK,

Between pin 4 and 8 = .48

Between the positive lead on the back of the DC jack and the negative pin - a soild 9.5 (just like the board).

Between the negative lead on the back of the DC jack and the positive pin - .48

So, I am getting a shot to the positive pin, right?


OK,

Between pin 4 and 8 = .48

Between the positive lead on the back of the DC jack and the negative pin - a soild 9.5 (just like the board).

Between the negative lead on the back of the DC jack and the positive pin - .48

So, I am getting a shot to the positive pin, right?
Well something is amiss there. With the black lead of your multimeter inserted into pin 4 & red lead of your multimeter inserted into pin 8 we should have 9V. So, we have a good ground at pin 4. With no power to the DC socket, can we check continuity (ohms scale of your meter) between the + of the DC socket & pin 8? Should read zero ohms.
Edit; I just looked at the time, I'm really late for work, I'll keep checking in with my phone. We will get it sorted. Cheers

Oh, cool. I just arrived at the property we are fencing to find the above post. Fingers crossed. I'll keep checking in. Cheers

Oh, cool. I just arrived at the property we are fencing to find the above post. Fingers crossed. I'll keep checking in. Cheers
OK, next problem. When the mini toggle to D5 & D6 (1588 diodes) is engaged, I get modulation sounds. When it is not, I get no sound. It appears to be in the righ polarity, assuming the blue band is the cathode end.

(Note edit above - the missing connection was to the 5817 diode.)

Well, I found another missed connection, but same result. Wacky noises!
I've built 4 pedals from kits. All of them included printed circuit boards. I've never done a build with a perf board. Populating a perf board has got to be more of a challenge.

  • Like
Reactions: RVA
I've built 4 pedals from kits. All of them included printed circuit boards. I've never done a build with a perf board. Populating a perf board has got to be more of a challenge.
At least I have power and some sort of noise! Maybe Ivan has an idea of what modulation without change when actually playing the guitar means. I will continue to re-trace my steps until I find out what it is. But for the rest of tonight, I am going to play the resistor diode blues on a tasty ax!

Last edited:
I found an improper ground to the input wire. I cleared tha up. I still get modulation, but I can hear notes. The nature of the modulation changes with the mini-toggles, and in one combo, I get silence. I am getting closer!

Ok, I knock off in a bit over half hour, then drive home & shower quickly, so a bit over an hour I'll look on computer, cant see much with phone. IIRC plexi asked for a schematic so I'll put that up now. This pedal only uses one half of the King of Tone circuit shown in the scematic. Power supply circuit is same. Back shortly. Cheers

  • Like
Reactions: RVA
King Of Tone schematic V__8C68.gif
The upper & lower effect circuit are identical. Only one is used in Prince of Tone

King Of Tone schematic View attachment 16764
The upper & lower effect circuit are identical. Only one is used in Prince of Tone
Thank you Ivan. These errors appear to be my difficulty following the schematic for the first time. I must continue to hunt down errors on the underside. Just let me know if you see any obvious errors on the top side of the board if you could please.

No problem. Do you happen to have something like a 10X magnifier or jewellers loupe to check all board tracks & connections with? I use these two magnifiersWP_20180724_002.jpg
The chrome, flip out one is 10X, the other "stand" type even stronger, & believe me, I have often needed them for this same reason, so don't beat yourself up.
Sysco, yes, a kit type build or a printed circuit board type build is very definitely easier, however I couldn't find (google search) a kit version of the POT, nor a Vero board (or stripboard) layout for it. This was the only one I could find,
AnalogMan Prince of Tone Perf and PCB Effects Layouts: AnalogMan Prince of Tone
Though I haven't built it yet, it is verified. The lower right diagram is for a "DIY printed circuit board", though I've never bothered to do one.
Ok, I'll spend some time reading posts & looking over the pics you posted earlier, & I'll also make sure I'm up & fresh for at least a few hours before I have to leave in the morning. Cheers
Edit; thankyou for helping Sysco, & I seriously wish I could do diagrams etc on a computer like you do. Unfortunately, I'm,,, digitally challenged. Cheers

Last edited:
No problem. Do you happen to have something like a 10X magnifier or jewellers loupe to check all board tracks & connections with? I use these two magnifiersView attachment 16765
The chrome, flip out one is 10X, the other "stand" type even stronger, & believe me, I have often needed them for this same reason, so don't beat yourself up.
Sysco, yes, a kit type build or a printed circuit board type build is very definitely easier, however I couldn't find (google search) a kit version of the POT, nor a Vero board (or stripboard) layout for it. This was the only one I could find,
AnalogMan Prince of Tone Perf and PCB Effects Layouts: AnalogMan Prince of Tone
Though I haven't built it yet, it is verified. The lower right diagram is for a "DIY printed circuit board", though I've never bothered to do one.
Ok, I'll spend some time reading posts & looking over the pics you posted earlier, & I'll also make sure I'm up & fresh for at least a few hours before I have to leave in the morning. Cheers
Edit; thankyou for helping Sysco, & I seriously wish I could do diagrams etc on a computer like you do. Unfortunately, I'm,,, digitally challenged. Cheers
That is nice of you. Don't go the too much trouble. The answer is there and I will find it. Being forced to correct a mistake is s great learning tool.

I have a florescent light which surrounds a big magnifier (what are those called again?!) which provides ample magnification

Do you happen to have something like a 10X magnifier or jewellers loupe to check all board tracks & connections with? I use these two magnifiers
wp_20180724_002-jpg.16765

The chrome, flip out one is 10X, the other "stand" type even stronger, & believe me, I have often needed them for this same reason, so don't beat yourself up.
I need to look into these again. I bought a real cheap one, and it's just about useless.

Edit; thankyou for helping Sysco, & I seriously wish I could do diagrams etc on a computer like you do. Unfortunately, I'm,,, digitally challenged. Cheers
The art of selecting; copying; pasting; add a few lines; easy peasy... When you're retired, you just have so much more time and patience to figure things out... :cheers:

I have a florescent light which surrounds a big magnifier (what are those called again?!) which provides ample magnification
Fluorescent Magnifier?

ThE following works for me as long as I have plenty of flooding light. It allows plenty of moving around freedom; fits over reading glasses; lenses are interchangeable. You can add a light ring around the lense, but it's not very bright:


I need to look into these again. I bought a real cheap one, and it's just about useless.


The art of selecting; copying; pasting; add a few lines; easy peasy... When you're retired, you just have so much more time and patience to figure things out... :cheers:


Fluorescent Magnifier?

ThE following works for me as long as I have plenty of flooding light. It allows plenty of moving around freedom; fits over reading glasses; lenses are interchangeable. You can add a light ring around the lense, but it's not very bright:

View attachment 16767
I have one of these, but those goggles are riotous !



Maybe the goggles work work well with this headlamp, which I use frequently



Last edited:
